Migrating from Endpoints to EndpointSlices in Kubernetes

Starting with Kubernetes 1.33, the traditional Endpoints API is officially deprecated. This change affects how Services map to backend Pods or external IPs. The newer EndpointSlice API provides better scalability, improved performance, and richer metadata capabilities.

If your cluster has been manually using Endpoints to map a Service to an external backend (for example, when the backend is not running inside Kubernetes), it’s time to migrate to EndpointSlice.

Example: Existing Endpoints-Based Configuration

Below is an example configuration using the deprecated Endpoints API:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: app-ingress
  labels:
    app: app-ingress
  annotations:
    kubernetes.io/ingress.class: "nginx"
spec:
  tls:
    - hosts:
        - app.example.com
      secretName: example-tls-secret
  rules:
    - host: app.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: external-backend
                port:
                  number: 9000
---
apiVersion: v1
kind: Service
metadata:
  name: external-backend
spec:
  ports:
    - port: 9000
      protocol: TCP
      targetPort: 9000
---
apiVersion: v1
kind: Endpoints
metadata:
  name: external-backend
subsets:
  - addresses:
      - ip: 192.168.1.50
    ports:
      - port: 9000
        protocol: TCP

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: app-ingress
  labels:
    app: app-ingress
  annotations:
    kubernetes.io/ingress.class: "nginx"
spec:
  tls:
    - hosts:
        - app.example.com
      secretName: example-tls-secret
  rules:
    - host: app.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: external-backend
                port:
                  number: 9000
---
apiVersion: v1
kind: Service
metadata:
  name: external-backend
spec:
  ports:
    - port: 9000
      protocol: TCP
      targetPort: 9000
---
apiVersion: v1
kind: Endpoints
metadata:
  name: external-backend
subsets:
  - addresses:
      - ip: 192.168.1.50
    ports:
      - port: 9000
        protocol: TCP

This configuration exposes the external IP 192.168.1.50:9000 via the Service external-backend and an NGINX Ingress route.

In Kubernetes 1.33 and above, you will start seeing deprecation warnings when reading or writing Endpoints objects. The new approach uses the EndpointSlice API.

Migrating to EndpointSlice

You can replace the Endpoints resource with a manually created EndpointSlice as shown below:

apiVersion: discovery.k8s.io/v1
kind: EndpointSlice
metadata:
  name: external-backend-static
  labels:
    kubernetes.io/service-name: external-backend
addressType: IPv4
ports:
  - name: ""
    port: 9000
    protocol: TCP
endpoints:
  - addresses:
      - 192.168.1.50

apiVersion: discovery.k8s.io/v1
kind: EndpointSlice
metadata:
  name: external-backend-static
  labels:
    kubernetes.io/service-name: external-backend
addressType: IPv4
ports:
  - name: ""
    port: 9000
    protocol: TCP
endpoints:
  - addresses:
      - 192.168.1.50

This EndpointSlice links to the same Service (external-backend) via the label kubernetes.io/service-name: external-backend. Once applied, traffic routed through the Service and Ingress will continue to function exactly as before.

What Happens When You Delete Endpoints

If you previously had both Endpoints and EndpointSlice objects for the same Service, you might wonder what happens if you delete the Endpoints.

There are two possibilities:

1. Auto-generated EndpointSlice
   If the EndpointSlice was automatically created by the Kubernetes controller (mirrored from an Endpoints object), deleting the Endpoints resource will also delete the related EndpointSlice.
2. Manually created EndpointSlice
   If you manually created the EndpointSlice (like the example above), deleting the Endpoints will not remove your EndpointSlice. It is fully independent, as long as it’s not listed under ownerReferences in its metadata.

You can verify this with the command:

kubectl get endpointslice external-backend-static -o yaml | grep ownerReferences

kubectl get endpointslice external-backend-static -o yaml | grep ownerReferences

If no owner is listed, the slice is managed manually and safe from automatic deletion.

Checking Existing Slices

Before deleting your old Endpoints, you can list all related slices:

kubectl get endpointslice -l kubernetes.io/service-name=external-backend

kubectl get endpointslice -l kubernetes.io/service-name=external-backend

If only your manually created slice (for example, external-backend-static) appears, you can safely delete the deprecated Endpoints resource:

kubectl delete endpoints external-backend

kubectl delete endpoints external-backend

Migrating to EndpointSlice ensures compatibility with future Kubernetes versions while improving scalability and performance. The migration is straightforward if you are manually defining external backends.
Simply create an EndpointSlice resource that maps to your Service, remove the old Endpoints, and your application traffic will continue to work seamlessly.
