Deploy Apache Kafka in KRaft Mode with Strimzi

Published on November 10, 2025

Introduction

This guide explains how to deploy a fully functional, high-availability Kafka cluster in KRaft mode using Strimzi 0.48.0 on Kubernetes.

When Bitnami recently restructured their repository access, many of their popular Helm charts – including those for Apache Kafka – became unavailable publicly. This change left many Kubernetes users, myself included, looking for reliable and production-ready alternatives.

After evaluating several options, I found Strimzi to be the most robust and Kubernetes-native way to deploy Kafka. Strimzi isn’t just another Helm chart – it’s a full-featured Operator built to manage Apache Kafka clusters declaratively within Kubernetes, including the modern KRaft mode (Kafka without ZooKeeper).

In this guide, I’ll walk you through deploying a production-ready Kafka cluster using Strimzi in KRaft mode, along with fixes for common RBAC permission issues you might encounter during installation.

Key Advantages of Strimzi

  • Native Kubernetes Integration – Seamlessly works with Kubernetes resources and APIs
  • Automatic Cluster Management – Handles recovery, scaling, and rolling upgrades
  • KRaft Mode Support – Deploy a lightweight, ZooKeeper-free Kafka cluster
  • Built-in Security – Supports TLS, authentication, and fine-grained authorization
  • Active Community – Backed by Red Hat and the Apache Kafka ecosystem

Prerequisites

Before starting, make sure you have:

  • A Kubernetes cluster (tested on v1.34.1; compatible with v1.28+)
  • At least 3 worker nodes (for high availability)
  • A functional StorageClass (this guide uses rook-cephfs)
  • kubectl configured to access your cluster
  • Basic understanding of Kubernetes resources (Pods, Deployments, CRDs, etc.)

Architecture Overview

Here’s what we’ll deploy:

ComponentPurpose
3 Kafka brokersHandle message streaming and data replication
3 Kafka controllersManage cluster metadata and consensus in KRaft mode
Entity OperatorManages Kafka topics and users
Strimzi Cluster OperatorAutomates Kafka lifecycle management

To ensure high availability, broker and controller pods will be distributed evenly across worker nodes using pod anti-affinity rules.

1. Install Strimzi Cluster Operator 0.48.0

# Create namespace
kubectl create namespace kafka

# Download and deploy Strimzi 0.48.0
STRIMZI_VERSION="0.48.0"
curl -L "https://github.com/strimzi/strimzi-kafka-operator/releases/download/${STRIMZI_VERSION}/strimzi-${STRIMZI_VERSION}.tar.gz" \
  -o strimzi-${STRIMZI_VERSION}.tar.gz
tar -xzf strimzi-${STRIMZI_VERSION}.tar.gz
cd strimzi-${STRIMZI_VERSION}

kubectl apply -f install/cluster-operator/ -n kafka

2. Fix RBAC Permissions

  • Strimzi’s default installation YAML files are hardcoded to use the myproject namespace (used in their examples)
  • When you install Strimzi in a different namespace (like kafka), the RoleBindings and ClusterRoleBindings still reference myproject in their subjects section
  • This causes the operator’s ServiceAccount to be in the wrong namespace context, leading to permission errors
  • Apply the following patches to fix them:
# Fix RoleBindings namespace
kubectl patch rolebinding strimzi-cluster-operator -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/subjects/0/namespace", "value": "kafka"}]'

kubectl patch rolebinding strimzi-cluster-operator-leader-election -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/subjects/0/namespace", "value": "kafka"}]'

kubectl patch rolebinding strimzi-cluster-operator-entity-operator-delegation -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/subjects/0/namespace", "value": "kafka"}]'

kubectl patch rolebinding strimzi-cluster-operator-watched -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/subjects/0/namespace", "value": "kafka"}]'

# Fix ClusterRoleBinding
kubectl patch clusterrolebinding strimzi-cluster-operator \
  --type='json' -p='[{"op": "replace", "path": "/subjects/0/namespace", "value": "kafka"}]'

# Add missing permissions
kubectl patch clusterrole strimzi-cluster-operator-global \
  --type='json' -p='[{"op": "add", "path": "/rules/-", "value": {
    "apiGroups": [""],
    "resources": ["nodes"],
    "verbs": ["get", "list", "watch"]
  }}]'

kubectl patch clusterrole strimzi-cluster-operator-global \
  --type='json' -p='[{"op": "add", "path": "/rules/-", "value": {
    "apiGroups": ["rbac.authorization.k8s.io"],
    "resources": ["clusterrolebindings"],
    "verbs": ["get", "list", "watch", "create", "patch", "delete"]
  }}]'

# Restart the operator to apply changes
kubectl rollout restart deployment strimzi-cluster-operator -n kafka

3. Create the Kafka Cluster Resource

In Strimzi 0.48.0, Kafka runs in KRaft mode by default.

Create the main cluster definition file kafka-cluster.yaml:

apiVersion: kafka.strimzi.io/v1beta2
kind: Kafka
metadata:
  name: kafka-cluster
  namespace: kafka
spec:
  kafka:
    version: 4.1.0
    listeners:
      - name: plain
        port: 9092
        type: internal
        tls: false
      - name: external
        port: 9094
        type: nodeport
        tls: false
        configuration:
          externalTrafficPolicy: Cluster
    config:
      offsets.topic.replication.factor: 3
      transaction.state.log.replication.factor: 3
      transaction.state.log.min.isr: 2
      default.replication.factor: 3
      min.insync.replicas: 2
      auto.create.topics.enable: "true"
      log.flush.interval.messages: "100000"
      log.flush.interval.ms: "5000"
      log.retention.bytes: "2147483648"
      log.retention.check.interval.ms: "300000"
      log.retention.hours: "72"
  entityOperator:
    topicOperator:
      resources:
        requests:
          memory: 128Mi
          cpu: 50m
        limits:
          memory: 512Mi
          cpu: 200m
    userOperator:
      resources:
        requests:
          memory: 128Mi
          cpu: 50m
        limits:
          memory: 512Mi
          cpu: 200m

4. Create Kafka Node Pools

KRaft requires separate node pools for brokers and controllers.

Brokers Node Pool (kafka-nodepool-brokers.yaml)

apiVersion: kafka.strimzi.io/v1beta2
kind: KafkaNodePool
metadata:
  name: brokers
  namespace: kafka
  labels:
    strimzi.io/cluster: kafka-cluster
spec:
  replicas: 3
  roles:
    - broker
  resources:
    requests:
      memory: 2Gi
      cpu: 1000m
    limits:
      memory: 4Gi
      cpu: 2000m
  storage:
    type: jbod
    volumes:
      - id: 0
        type: persistent-claim
        size: 8Gi
        deleteClaim: false
        class: rook-cephfs
  template:
    kafkaContainer:
      env:
        - name: KAFKA_HEAP_OPTS
          value: "-Xmx2048m -Xms2048m"
    pod:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
            - weight: 100
              podAffinityTerm:
                labelSelector:
                  matchLabels:
                    strimzi.io/cluster: kafka-cluster
                    strimzi.io/kind: Kafka
                    strimzi.io/pool-name: brokers
                topologyKey: kubernetes.io/hostname

Controllers Node Pool (kafka-nodepool-controllers.yaml)

apiVersion: kafka.strimzi.io/v1beta2
kind: KafkaNodePool
metadata:
  name: controllers
  namespace: kafka
  labels:
    strimzi.io/cluster: kafka-cluster
spec:
  replicas: 3
  roles:
    - controller
  resources:
    requests:
      memory: 1Gi
      cpu: 500m
    limits:
      memory: 2Gi
      cpu: 1000m
  storage:
    type: jbod
    volumes:
      - id: 0
        type: persistent-claim
        size: 8Gi
        deleteClaim: false
        class: rook-cephfs
  template:
    pod:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
            - weight: 100
              podAffinityTerm:
                labelSelector:
                  matchLabels:
                    strimzi.io/cluster: kafka-cluster
                    strimzi.io/kind: Kafka
                    strimzi.io/pool-name: controllers
                topologyKey: kubernetes.io/hostname

5. Deploy the Kafka Cluster

# Deploy the main cluster
kubectl apply -f kafka-cluster.yaml

# Then deploy node pools
kubectl apply -f kafka-nodepool-controllers.yaml
kubectl apply -f kafka-nodepool-brokers.yaml

# Wait for the cluster to become ready
kubectl wait --for=condition=Ready kafka/kafka-cluster -n kafka --timeout=600s

6. Configure External Access (NodePorts) (Optional)

To allow external clients to connect, patch the broker services with custom NodePorts:

kubectl patch svc kafka-cluster-brokers-0 -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/spec/ports/0/nodePort", "value":32501}]'

kubectl patch svc kafka-cluster-brokers-1 -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/spec/ports/0/nodePort", "value":32502}]'

kubectl patch svc kafka-cluster-brokers-2 -n kafka \
  --type='json' -p='[{"op": "replace", "path": "/spec/ports/0/nodePort", "value":32503}]'

7. Deploy Kafdrop (Optional)

For monitoring topics and messages, deploy Kafdrop.

Create kafdrop.yaml:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: kafdrop
  namespace: kafka
spec:
  replicas: 1
  selector:
    matchLabels:
      app: kafdrop
  template:
    metadata:
      labels:
        app: kafdrop
    spec:
      containers:
      - name: kafdrop
        image: obsidiandynamics/kafdrop:latest
        ports:
        - containerPort: 9000
        env:
        - name: KAFKA_BROKERCONNECT
          value: "kafka-cluster-kafka-bootstrap:9092"
        - name: SERVER_SERVLET_CONTEXTPATH
          value: "/"
---
apiVersion: v1
kind: Service
metadata:
  name: kafdrop
  namespace: kafka
spec:
  ports:
  - port: 9000
    targetPort: 9000
  selector:
    app: kafdrop
  type: ClusterIP

Deploy it:

kubectl apply -f kafdrop.yaml

Final Architecture Overview

ComponentReplicasRoleDescription
Controller Pods3Cluster metadata managementHandle coordination and leadership
Broker Pods3Data processingManage topics, partitions, and replication
Entity Operator1User/topic automationMaintains Kafka users and topics
Kafdrop (optional)1UIVisualizes cluster data
